Specifications:
Image Sensor: 1/3 color COMS sensor
Display Resolution: 1280*720 @ 30fps
Lens: f : 3.6mm, F : 2.0 ( IR lens )
Mini Illumination: 0.5 Lux
View Angle : 140 degree
Audio Input: Built-in microphone
Audio Output: One channel audio output
Audio Compression: G.711
Image Compression: H.264 MJPEG
Image Frame Rate: 30 fps(VGA) 30fps(QUVGA)
Resolution: Primary stream :1280*720 640*368 320*208
Flip Mirror Images: Vertical Horizontal
Light Frequency: 50Hz 60Hz Outdoor
Video Parameters: Brightness Saturation Contrast Hue
Ethernet Interface: Built-in 10/100Mbps. Auto MDI/MDIX, RJ-45
Supported Protocols: HTTP DNS DHCP PPPoE SMTP FIP SSL TFTP NTP ARP RARP NFS RTSP RTP RTCP
Compress Rate Level: 128kbps~ 4Mbps
Wireless Standard: IEEE 802.11b/g/n
Data Rate: 802.11b: 11Mbps (Max) 802.11g: 54Mbps(Max) 802.11n:150 Mbps(Max)
Wireless Security : WEP WPA WPA2 Encryption
Infrared Light: 10 IR lights , night visibility up to 15 meters
Alarm Input: One channel ON/OFF input
Alarm Output: 1 channel relay output
Power Supply: DV 5V 2.0A (ES US AU adapter or other types optional )
Power Consumption: 7 watts (Max)
Operate Temp.: 0°C-55°C
Operate Humidity: 20%-85% non-condensing
Storage Temper: -10°C~60°C
Storage Humidity : 0%-90% non-condensing
CPU: 2.0GHZ or above (Suggested 3.0 GHZ)
Memory Size: 256MB or above (Suggested 1.0 GHZ)
Display Card: 64M or above
Support OS: 2000/XP/Vista/7
Browser: IE 6.0/7.0/8.0/Firefox/Safari/Google others
- Image Sensor: 1/3 color COMS Sensor
- Display Resolution: 1280*720 @ 30fps
- Lens: f : 3.6mm, F : 2.0 ( IR lens )
- Mini Illumination: 0.5 Lux
- View Angle : 140 degree
- Audio Input: Built-in microphone
- Audio Output: One channel audio output
- Audio Compression: G.711
- Image Compression: H.264 MJPEG
- Image Frame Rate: 30 fps(VGA) 30fps(QUVGA)
- Resolution: Primary stream :1280*720 640*368 320*208
- Flip Mirror Images: Vertical Horizontal
- Light Frequency: 50Hz 60Hz Outdoor
- Video Parameters: Brightness Saturation Contrast Hue
- Ethernet Interface: Built-in 10/100Mbps. Auto MDI/MDIX, RJ-45
- Supported Protocols: HTTP DNS DHCP PPPoE SMTP FIP SSL TFTP NTP ARP RARP NFS RTSP RTP RTCP
- Compress Rate Level: 128kbps~ 4Mbps
- Wireless Standard: IEEE 802.11b/g/n
- Data Rate: 802.11b: 11Mbps (Max) 802.11g: 54Mbps(Max) 802.11n:150 Mbps(Max)
- Wireless Security : WEP WPA WPA2 Encryption
- Infrared Light: 10 IR lights , night visibility up to 15 meters
- Alarm Input: One channel ON/OFF input
- Alarm Output: 1 channel relay output
- Power Supply: DV 5V 2.0A (ES US AU adapter or other types optional )
- Power Consumption: 7 watts (Max)
- Operate Temp.: 0°C-55°C
- Operate Humidity: 20%-85% non-condensing
- Storage Temper: -10°C~60°C
- Storage Humidity : 0%-90% non-condensing
- CPU: 2.0GHZ or above (Suggested 3.0 GHZ)
- Memory Size: 256MB or above (Suggested 1.0 GHZ)
- Display Card: 64M or above
- Support OS: 2000/XP/Vista/7
- Browser: IE 6.0/7.0/8.0/Firefox/Safari/Google others
