Wireless Kit WC29

Wireless Network home surveillance Kit Baby Care Nanny 4-Channel Receiver Waterproof Night Vision IR Security Cameras

Specifications:

• Transmission Frequency: ISM 2,400MHz~ 2,483MHz 4CH


• Modulation Mode: FM


• Antenna Type: Omni


• Unobstructed Effective Range: 100m(Without Block)


• Operating Humidity: 85% RH


• Imaging Sensor Type: 1/3" OmnVision CMOS


• PAL: 628×582


• NTSC: 510×492


• Horizontal Resolution: 380 TV Lines


• View Angle: 55°


• Minimum Illumination: 1.0 Lux/F1.2(IR ON)


• Transmission Power: 80mW


• Power Supply: DC 12V 1000mA


• Night Vision Range: 8m


• Consumption Current: 80mA, 200mA(IR ON)


• Dimensions: ¢35mm x 60mm


• Weight: 185 g


• Receiving Sensitivity: ≤-85dBm


• Antenna Port: 50ohm SMA


• Power Supply: DC 12V 500mA


• Consumption Current: 240mA


• Video Output Level: 1Vp-p@75Ω


• Audio Output Level: 1Vp-p@10KΩ


• Dimensions: 100(W) x 80(D) x 30(H) mm


• Weight: 110 g

Package Includes:

• 1x Receiver


• 2x Cameras


• 1x Remote Control


• 1x Power Adapter for Receiver


• 1x Power Adapter for Cameras


• 1x AV Cable


• 1x User Manual
